Chazy Control Pro
Unlocking control. Instantly.
SKU - CHZ-CTRLPRO
The Chazy Control Pro box unlocks the full potential of the Chazy 4K Family, embedding Dante Controller directly in hardware for seamless routing and management via any web browser.
- Web-based GUI for intuitive control
- Multicast support for efficient network usage
- Video wall configurations up to 9x9
- Built-in KVM (keyboard, video, mouse) switching
- API integration with Q-SYS, Crestron & more
- Group receivers for synchronized playback
- Trigger commands via serial (RS-232), IP or IR
- Scheduling and automation capabilities
- PoE powered for clean installs
- Fanless and silent operation
Seamless Management
Control your entire Chazy AV over IP deployment using only a browser. No apps. No licenses. Just smooth, direct access to everything you need.
Video Walls. Made Easy.
Create up to 9x9 video wall layouts with pixel-perfect alignment. Set up once and control it forever—or until the next big event.
Advanced API Integration
Fully integrable with leading control systems like Q-SYS and Crestron. Build the smart room of your dreams.
Group. Trigger. Automate.
From IR to RS-232 to scheduled tasks—Chazy Control Pro handles it all. Set up triggers across devices and automate complex AV workflows like a boss.
Dante + Chazy = Harmony
With Dante Controller embedded directly into the unit, you’re one click away from pure AV/audio sync bliss across your entire Dante network.
Technical Specifications
| Feature | Description |
|---|
| Network Protocols | Multicast, Unicast, IGMP v2/v3 |
| Control Interface | WebGUI (HTML5 browser-based) |
| AV System Compatibility | Q-SYS, Crestron, AMX, Extron |
| Video Wall Support | Up to 9x9 layout (81 displays) |
| KVM Functionality | USB HID switching over IP |
| Command Triggers | RS-232, IP, IR |
| Audio | Dante embedded (via Dante Controller) |
| API Access | RESTful API with full documentation |
| Network Ports | 1x RJ45 1GbE (PoE+) port |
| Power | PoE+ IEEE 802.3at or DC 12V/2A input |
| Security | HTTPS, User Login, Role-Based Access |
| Software Updates | Web-based, over LAN |
| Latency | <1ms pass-through control latency |
| Compliance | CE, FCC, RoHS |
Mechanical Specifications
| Feature | Description |
|---|
| Housing | Metal, Fanless |
| Color | Chazy Graphite Black |
| Dimensions | 100mm [W] x 100mm [D] x 28mm [H] |
| Weight | 280g |
| Power Input | DC 12V/2A or PoE+ (IEEE 802.3at) |
| Power Consumption | Max 11W |
| Operating Temperature | 32°F – 104°F / 0°C – 40°C |
| Storage Temperature | -4°F – 140°F / -20°C – 60°C |
| Operating Humidity | 20% – 80% relative humidity, non-condensing |
| Storage Humidity | 10% – 90% relative humidity, non-condensing |
| Mounting | Wall/VESA/rack mount options included |
