Mipro ACT-311(II)/ACT-32H Håndsett 8A-A (822~832MHz)
ACT-311(II)/ACT-32H komplett trådløst mikrofon sett, mottager med håndmikrofon/sender ACT-32H.
Mipro ACT-311(II)
- CPU-controlled diversity receiving. "PiloTone & NoiseLock" dual-squelch circuit eliminates signal drop-out and minimizes interference.
- All controls are intuitive and easily operated via electronic buttons to prevent accidental operation.
- Industry’s only RF interference warning indicator for proper adjustments of the SQ level. Increase sensitivity to extend receiving range; decrease the sensitivity to reduce interference.
- Auto Scan function allows quick search for an interference-free working channel. World’s first ACT™ function provides precise and rapid frequency sync to the transmitters.
- Output level is pre-adjusted to equal the microphone capsule’s sensitivity. Switchable output levels for the best sound quality options.
- Receiver provides bias voltage for MIPRO antenna systems to enhance reception range and signal stability.
| Channel | Single | |
| | Chassis | EIA Standard 19 " 1/2U metal chassis | |
| | Display | Green backlit LCD with automatic bright (working) and dim (standby) displays during performance. | |
| | Frequency Range | UHF 480 ~ 934 MHz (country dependent) | |
| | Bandwidth | 24 MHz | |
| | Deviation | < ± 40 kHz | |
| | Receiving Mode | CPU-controlled diversity receiving | |
| | Sensitivity | 10 dBµV at S/N > 80 dB | |
| | S/N Ratio | > 106 dB(A) | |
| | T.H.D. | < 0.5% @ 1 kHz | |
| | Frequency Response | 50 Hz ~ 18 kHz | |
| | Squelch | “PiloTone & NoiseLock” dual-squelch circuit | |
| | Audio Output | Balanced XLR & Unbalanced Ø 6.3 mm | |
| | Max. Output Level | Balanced: 0 dBV ; Unbalanced: +10 dBV / 0 dBV | |
| | Power Supply | 12 ~ 15 V DC, 1A | |
| | Dimensions (W × H × D) | 210 × 44 × 180 mm / 8.3 × 1.7 × 7.1 " | |
| | Net Weight | Approx. 0.8 kg / 1.8 lbs |
Mipro ACT-32H
- Innovatively designed metal housing in MIPRO’s distinctive aesthetic and ergonomic style.
- Interchangeable capsule module with premium condenser or dynamic options for easy and fast changeovers. The unique multi-layered metal grille protects the capsule against impact, rolling and pop noise, ensuring clarity of sound. The upper grille is easy to detach for cleaning and hygiene practice.
- Patented capsule suspension design virtually eliminates vibration and handling noises.
- Built-in high-efficiency antenna.
- Backlit LCD displays all operational parameter information.
- World’s first ACT™ function provides precise and rapid frequency sync to the receiver.
| Housing | Black-color rugged plastic housing | |
| | Display | LCD displays all operational parameter information. | |
| | Frequency Range | UHF 480 ~ 934 MHz (country dependent) | |
| | Bandwidth | 24 MHz | |
| | RF Output Power | 10 ~ 30 mW (country dependent) | |
| | Deviation | < ± 40 kHz | |
| | Spurious Emissions | < -55 dBc | |
| | Gain | 0 dB = input microphone sensitivity. High-fidelity modulation circuit sustains high SPL without distortion. | |
| | Dimensions (Ø × L) | 51 × 234 mm / 2 × 9.2 " | |
| | Net Weight | Approx. 251 g / 8.9 oz | |
| | Battery | 2 × AA alkaline | |
| | Operating Time | Min. 12 hours |
