Magewell Ultra Encode SDI Gen 2
Ultra Encode SDI
A Flexible & Affordable Universal Encoder
SKU: 531200000
Live H.264/H.265 streaming
Supports streaming protocols including SRT, NDI
®
|HX, HLS & more
Suitable for various network environment
Ultra Encode SDI Specifications
Download
Input & Loop-through
SDI
Supports SD (ST 259)/HD (ST 292)/3Ga (ST 425)/3Gb (ST 425)/3Gb-DL(ST 425)/3Gb-DS(ST 425) standards
Typical resolution/frame rate:
2048x1080p/2048x1080i 23.98/24/25/29.97/30/47.95/48/50/59.94/60
1920x1080p/1920x1080i 23.98/24/25/29.97/30/47.95/48/50/59.94/60
1280x720p 25/29.97/30/50/59.94/60
720x576 25p/50i (PAL SD)
720x480 29.97p/59.94i (NTSC SD)
Color sampling: YCbCr 10-bit 4:2:2, YCbCr 10-bit 4:4:4:4, YCbCr 12-bit 4:2:2, YCbCr 12-bit 4:4:4
Audio
SDI embedded audio: 16-Channel, 24-bit, 192kHz sample rate
Audio from 3.5 mm LINE IN: 2-Channel, 24-bit, 192kHz sample rate
Encode
Video
Bitrate: 16Mbps
Dual-stream encoding: main stream and sub stream
Main stream Resolution/frame rate:
2048x1080p/1920x1200p 60/59.94/50/30/29.97/25/24/15/10/5
1920x1080p/1920x720p 60/59.94/50/30/29.97/25/24/15/10/5
1664x936p/1600x1200p/1600x900p 60/59.94/50/30/29.97/25/24/15/10/5
1440x1080p/1440x900p 60/59.94/50/30/29.97/25/24/15/10/5
1280x1024p/1280x960p/1280x800p/1280x720p 60/59.94/50/30/29.97/25/24/15/10/5
1024x768p 60/59.94/50/30/29.97/25/24/15/10/5
960x540p/800x600p 60/59.94/50/30/29.97/25/24/15/10/5
768x576p/720x576p/720x540p/720x480p 60/59.94/50/30/29.97/25/24/15/10/5
640x480p/640x360p 60/59.94/50/30/29.97/25/24/15/10/5
480x360p/480x270p 60/59.94/50/30/29.97/25/24/15/10/5
Native CEA–608/608 over 708 captions
Sub stream
Supports enabling/disabling sub stream
Resolution/frame rate:
1920x1080p/1920x720p 60/59.94/50/30/29.97/25/24/15/10/5
1664x936p/1600x1200p/1600x900p 60/59.94/50/30/29.97/25/24/15/10/5
1440x1080p/1440x900p 60/59.94/50/30/29.97/25/24/15/10/5
1280x1024p/1280x960p/1280x800p/1280x720p 60/59.94/50/30/29.97/25/24/15/10/5
1024x768p 60/59.94/50/30/29.97/25/24/15/10/5
960x540p/800x600p 60/59.94/50/30/29.97/25/24/15/10/5
768x576p/720x576p/720x540p/720x480p 60/59.94/50/30/29.97/25/24/15/10/5
640x480p/640x360p 60/59.94/50/30/29.97/25/24/15/10/5
480x360p/480x270p 60/59.94/50/30/29.97/25/24/15/10/5
H.264/H.265 (HEVC) Codec:
System timecode or RP–188 standard timecode for SEI Message setting
H.265 (HEVC) SEI message supports carrying interlacing signal mark
Video aspect ratio conversion
Audio
2-channel AAC audio
Bitrate: 256/192/128/96/64/48/32/16 kbps
Output source embedded audio and line in through LINE OUT
Live stream
Natively supports streaming to:
Twitch
YouTube, publishing to timeline or a new event and setting “made for kids”
Facebook, enabling backup stream and publishing to timeline, business page or a new event
Supports streaming protocols:
RTSP
RTMP/RTMPS
SRT Caller/SRT Listener
NDI HX2
HLS
TS over UDP/TS over RTP
TVU ISSP
Supports sessions over the same streaming protocol, such as
Up to 6 sessions of TS over RTP and TS over UDP simultaneously
Up to 6 sessions of SRT Caller and SRT Listener simultaneously, containing one SRT Listener session at most (max 8 clients simultaneously)
Up to 6 sessions of RTMP and RTMPS simultaneously
Supports streaming only 1 session of HLS and RTSP
Supports streaming 2 sessions of NDI HX2
Supports specifying a video stream and an audio stream for each streaming session
Supports NDI 6.x
Web UI
Access Web UI via PC and smartphone
View real-time device status
Preview encoded video
Set input sources
Customize encoding parameters
Manage streaming destinations, start/stop streaming, view streaming status
Set up to 8 overlays for each stream, including text, picture, and clock
Update firmware
Supports registering Magewell Control Hub for centralized management
Supports Microsoft Edge/Firefox/Chrome/Safari/Opera web browsers
API
Provides APIs for 3rd party control system
Network Connections
Ethernet: 1x RJ45 port, 10/100/1000 Mbps Base-T
Wi-Fi: 802.11 a/b/g/n/ac, Station and AP modes supported
4G/5G USB modem (not supplied)
USB Net
Input/Output Ports
2 x SD/HD/3G BNC ports
1 x Input
1 x Loop-through
1 x 3.5mm LINE IN
1 x 3.5mm LINE OUT
1 x USB Type-A
LED Indicators
LEDs indicating the status of power, input signal, streaming, Ethernet and Wi-Fi connection
Power Supply and Consumption
DC 5V/3A
Max power consumption: ~7.16W
Form Factor
106.6mm x 106.2mm x 25mm
Accessories
1 x 5V Power Adapter
1 x USB Type A to Type B cable
1 x Wi-Fi Antenna
1 x T-bracke
Screw Mounting Hole
2 x M3 threaded hole
A standard 1/4"-20 socket provided by T-bracket
Working Environment
Operating temperature: 0 to 40 deg C
Storage temperature: –20 to 70 deg C
Relative humidity: 5% to 90% non-condensing
