LinkIT Wall Cabinet 9U Grey W600xD600xH501 | Glass

LinkIT Wall Cabinet is a robust and space-saving cabinet designed for professional network and IT installations. The cabinet features a tempered glass door with a solid frame, cylinder lock, and removable side panels with lock for easy access and increased security. Multiple cable entries on the top, bottom, and rear provide flexible installation and efficient cable management. Integrated grounding studs ensure safe operation. The cabinet is compatible with standard 19” rack equipment and is supplied with screws, cage nuts, and mounting tool for easy installation. Available in multiple heights, depths, and colors to suit various installation requirements. CE and RoHS compliant with a 10-year warranty.

Main Specifications

Brand LinkIT

Color Grey

Width (mm) 600

Depth (mm) 600

Height (mm) 501

Cable bushings Top, bottom and rear

Number of height units 9U

Max load capacity (kg) 70

Weight Lift 20,00

Color (RAL) 9004

Extended Specifications

Degree of protection (IP) 20

Front door Tempered Glass door with solid door border

Front door locking system Cylinder lock

Rear Door N/A

Rare door locking system N/A

Sidepanels Removable with lock

Max Mounting Depth (mm) 547

Standard Mounting Depth (mm) 447

Grounding With grounding studs, no grounding cable

Rail type L Type

Rail number 4

Guarantee (years) 10

Certifications CE, RoHS

Accessories 10 screws and cage nuts, 1 wrench
