LinkIT fiber OS2 24 Core SC-SC 30m CPR
24x fanout | 9/125 | LSZH | PTPS
This fiber cable is an OS2 Singlemode 9/125 type with 24 core fibers, and it comes in yellow color. It is preterminated with SC-UPC connectors on both ends (8 connectors on each end), each featuring a pull tube or pulling sock design. The cable has a fanout length of 0.5 meters with a diameter of 0.9 mm. It has low attenuation of 0.40 dB/km at 1310nm and 0.30 dB/km at 1550nm. Maximum load varies from N1200 to 500 depending on length, and it has a maximum bend radius of 20D dynamically and 10D statically. It is designed for temperatures ranging from -20°C to +70°C and weighs 67g per meter. The cable features a loose tube structure with G652D fiber and has a diameter of 6.2mm. It is halogen-free (LSZH) and suitable for both indoor and outdoor use.
- 24 core, fanout both ends
- Halogenfree cable (LSZH)
- LooseTube
- Yellow
- CPR Class: B2ca-s1a,d0,a1
Main Specifications
| Brand | LinkIT |
|---|
| Color | Yellow |
|---|
| Length (m) | 100 |
|---|
| Category | OS2 24 fiber |
|---|
| Connector type 1 | SC |
|---|
| Connector type 2 | SC |
|---|
| Polishing contact 1 | UPC |
|---|
| Polishing contact 2 | UPC |
|---|
| Number of fibers | 24 |
|---|
| Core Diameter (um) | 9/125 Singlemode |
|---|
Extended Specifications
| Optical Return Loss (dB) | >50 |
|---|
| Insertion Loss (dB) | <0.25 |
|---|
| Operating Temperature | -20~+70 |
|---|
| Storage Temperature | -20~+70 |
|---|
| Cable Diameter (mm) | 8.2 |
|---|
| Fire properties | IEC 60332-1-2, IEC 60754-1 , IEC 61034, IEC-60332-3-24 |
|---|
| Halogenfree | Yes |
|---|
| EAN | 7072262012421 |
|---|
| Tensile loads (N) | N1200/5000 |
|---|
| Fanout | 0,5m / Ø0,9mm |
|---|
| Certifications | CE, REACH, RoHS |
|---|
| Max bend radius (D) | 20D / 10D |
|---|
