LinkIT fiber OM4 8 Core LC-LC 50m
8x fanout | 50/125 | LSZH | PTP
This is a magenta OM4 Multimode 50/125 fiber cable with eight core fibers. It has a fanout of 50 cm with LC-UPC connectors on both ends (8 connectors on each end), each with a pull tube on side A and a pull sock on side B. The fanout length is 0.5 meters with a diameter of 0.9 mm. Insertion loss is less than 0.25 dB, and return loss is over 20 dB. It can withstand a tensile load of 5N and has maximum/minimum bend radii of 20D/10D. It operates at wavelengths of N850/1550 and has a temperature range from -20°C to +70°C. The cable has tight buffering with G652D fibers and a diameter of 6.2 mm. It weighs 67 g per meter and has a CPR grade of Cca – s1a, d1, a1. The cable is halogen-free (LSZH).
- 8-core with fanout 50cm
- Halogenfree cable (LSZH)
- Magenta
Main Specifications
| Brand | LinkIT |
|---|
| Color | Magenta |
|---|
| Length (m) | 50 |
|---|
| Category | OM4 |
|---|
| Connector type 1 | LC |
|---|
| Connector type 2 | LC |
|---|
| Polishing contact 1 | UPC |
|---|
| Polishing contact 2 | UPC |
|---|
| Number of fibers | 8 |
|---|
| Core Diameter (um) | 50/125 |
|---|
Extended Specifications
| Optical Return Loss (dB) | >35 |
|---|
| Insertion Loss (dB) | <0.25 |
|---|
| Operating Temperature | -20~+70 |
|---|
| Storage Temperature | -20~+70 |
|---|
| Cable Diameter (mm) | 6.2 |
|---|
| Cable fire class | Cca – s1a, d1, a1 |
|---|
| Fire properties | IEC 60332-1-2, IEC 60754-1 , IEC 61034, IEC-60332-3-24 |
|---|
| Halogenfree | Yes |
|---|
| EAN | 7072262010717 |
|---|
| Tensile loads (N) | 5N |
|---|
| Fanout | 0,5 meter / Ø0,9mm |
|---|
| Certifications | CE, REACH, RoHS |
|---|
| Max bend radius (D) | 20D / 10D |
|---|
