LinkIT 2U Slim Panel – 24x MPO Cassettes (up to 288 fibers)
LinkIT 2U slim panel for 24xMPO cassettes, supporting up to 288 fibers.
Delivered without cassettes – these must be purchased separately.
High-density patch panels are an effective way to increase the copper port density in racks and rack cabinets.
While standard patch panels offer 24 ports in a rack unit, high-density panels can double that amount with up to 48 ports per rack unit.
Main Specifications
| Brand | LinkIT |
|---|
| Color | Black |
|---|
| Measurements (WxHxD) | 482.6 × 88.1 × 455 mm |
|---|
| Material | Steel, Plastic |
|---|
| Number of height units | 2U |
|---|
| Number of fibers | 288 |
|---|
| Rack mounting | 19" |
|---|
| Number of outputs | 24 |
|---|
Extended Specifications
| Measure cable outlet holes | 65 × 43 mm |
|---|
| Measure entrance hole | 135 × 43 mm |
|---|
| Plug-in top plate | Yes |
|---|
| Cable guide | Yes |
|---|
| Removable drawer | Yes |
|---|
| Removable front plate | Yes |
|---|
