D226
Standard I/O Package
Built for interactive experiences that leverage Full HD to 4K video, 10-bit HDR support, and 2D motion graphics.
Ensure uninterrupted content with a secure internal microSD socket.
Deliver high-quality visuals on any location using an optional LTE modem
Technical Specifications
| HD226 | HD1026 |
|---|
Input/Output
| Standard | Expanded |
| 4K Video Decoding | Single 10-bit at 60p | Single 10-bit at 60p |
| Full HD at 60p Video Decoding | X (dual) | X (dual) |
HTML5 Performance Level
| Modular 2D motion
graphics | Interactive 2D motion
graphics |
| 10-bit HDR Support | X | X |
| Streaming | 4K IP streaming | 4K IP streaming |
| 4K Video Codecs: H.265/HEVC, H.264/AVC (max 30p), VP9 | X
H.265 at 60p
H.264 at 30p
| X
H.265 at 60p
H.264 at 30p
|
Video Containers
| 4K & Full HD: .MP4, .MOV, .MKV, .WEBM, .TS, .MPG, .MPEG, .PS, .M2P, .MPV, .AVI, .HEVC, .H264, .AV1, .VP9, and .MJPG | 4K & Full HD: .MP4, .MOV, .MKV, .WEBM, .TS, .MPG, .MPEG, .PS, .M2P, .MPV, .AVI, .HEVC, .H264, .AV1, .VP9, and .MJPG |
| HDMI® Outputs | 1x HDMI® 2.0a | 1x HDMI® 2.0a |
| USB | | 1x USB-A |
| Internal M.2 Socket for LTE | X | X |
| 3.5mm Serial | | X |
| M.2 E Key for WiFi/Bluetooth Module | X | X |
| Dimensions (W x D x H) | 205 x 185.9 x 19.2mm | 205 x 185.9 x 19.2mm |
| Warranty, Parts & Labor | 5 years | 5 years |
