WyreStorm 48Gbps 8K 4:4:4 Active Optical HDMI Cable | eARC, CEC, ALLM & VRR | ISF Certified

SKU: CAB-HAOC-FRL-xx

The WyreStorm HAOC is a next-generation HDMI cable built to handle the demands of 8K and high-frame-rate 4K HDR content. Utilizing a 4-core optical transmission system, this hybrid cable delivers uncompressed signals at up to 48Gbps bandwidth with full support for HDMI 2.1 features such as eARC, ALLM, VRR, and CEC. Certified by ISF, the HAOC-FRL is a future-ready solution for professional and home cinema environments.

Key Features

• 48Gbps bandwidth: Supports 8K/60Hz 4:4:4, 4K/144Hz, and 2K/240Hz with lossless clarity
• HDMI 2.1 Ready: Compatible with FRL (Fixed Rate Link), DSC, and HDCP 2.3
• True passive HDMI communication: Seamlessly transmits audio/video and metadata bidirectionally
• Universal HDR support: Includes HDR10+, Dolby Vision, HLG, SL-HDR1, and PQ
• Perfect for long-distance transmission: Immune to EMI/RFI interference with kevlar-protected cores
• High quality materials: Aluminum construction with slim 20mm (0.79”) TX head

Technical Specifications

• Transmission: Uncompressed AOC with DSC support (Source–Display when needed)
• Latency: 10µs end-to-end
• Max Bitrate: 48Gbps (4 x 12Gbps lanes)
• HDMI Version: HDMI 2.0b (TMDS) / HDMI 2.1 FRL (16b/18b encoding)
• Video Resolutions:
  • 1920 x 1080p @240Hz
  • 2560 x 1440p @240Hz
  • 4096 x 2160p @144Hz
  • 5120 x 2880p @60Hz
  • 7680 x 4320p @60Hz
• HDR Standards: HDR10, HDR10+, Dolby Vision, HLG, SL-HDR1, PQ
• Audio: eARC support | Up to 32 channels | Dolby Atmos | DTS:X | 192kHz max sampling rate
• Control Features: Bi-directional CEC | EDID Pass-through | ALLM | VRR
• HDCP: Pass-through | HDCP 2.3 supported
• Ethernet: 100Mbps supported
• Power: 4.5V–5.5V passive from connected source | Max 250mW

What’s in the Box

• 1x CAB-HAOC-FRL-10 or CAB-HAOC-FRL-15 Active Optical HDMI Cable
• 2x Reusable cable ties
• 1x Quickstart guide

Supplied coiled on recyclable cardboard spool – no single-use plastic included (#SUPFree).
